SZ-65W3P-G
 SZ POWER TECHNOLOGY CO.,LTDwww.szpowertechnology.com |
|||||
| FEATURES | CERTIFICATIONS | PRODUCT IMAGE | |||
|
※ 65W OUTPUT POWER ※ 3A MAX FAST SPEED CHARGING ※ OVERCURRENT PROTECTION ※ SHORT CIRCUIT PROTECTION ※ INPUT PROTECTION |
|
 |
|||
| TYPICAL MODEL LIST | |||||
| I/P VOLTAGE | MODEL | OUTPUT | PORT STYLE | EFFICIENCY | |
|
90V-264A AC 47-63Hz |
SZ-65W3P-G |
AC Input: AC 100V～240V, 50/60 Hz, 1.8A Total Output: 65W Max USB-C PD Output1: 5V 3A; 9V 3A; 12V 3A; 15V 3A; 20V 3.25A, 65W Max(Support QC 3.0: 5.0~12V,3A Max) USB-C PD Output2: 5V 3A; 9V 3A; 12V 3A; 15V 3A; 20V 3.25A, 65W Max(Support QC 3.0: 5.0~12V,3A Max) USB-A Output3: 5V2.4A, 12W C1+C2=PD45W+PD20W;C1+A=PD45W+12W;C2+A=PD45W+12W; C1+C2+A=PD27W+PD20W+12W
|
TYPE-C PORT + TYPE-A PORT |
|
|
| OUTPUT SPECIFICATIONS | ENVIRONMENTAL SPECIFICATIONS | ||||
| OUTPUT POWER | 65W | OPERATING TEMP. | 0℃~ 25℃ | ||
| STANDBY POWER | ＜0.075W | COOLING | CONVECTION | ||
| LEAKAGE CURRENT |
＜0.25mA (230Vac/50Hz) |
TEMP. COEFFICIENT | 0.05%/°C | ||
| RIPPLE & BOISE | V x 2%mVp-p @ 25 °C | HUMIDITY |
0%~95% (non-condensing) |
||
| START UP TIME | ＜2S | STORAGE TEMP. | -25℃~ +55℃ | ||
| LINE REGULATION | V±2.0% | ||||
| OUTPUT REGULATION | ±5% | ||||
| PROTECTIONS | Over voltage protection,Short circuit protection,Over current protection,Thermal protection | ||||
| SAFETY STANDARDS | |||||
| PRODUCT DIMENSIONS | |||||
